Tolerance Analysis of Electronic Circuits Using MATHCAD
Taylor & Francis

Tolerance Analysis of Electronic Circuits Using MATHCAD

Edition: 1st Edition
Subjects: Engineering, Environmental science, engineering & technology
ISBN13: 9780849323393
Published: 24 Sep 1999

Format - Paperback / softback
By Robert Boyd

Usually ready in 7-10 business days.

A$121.60
A$121.60 A$152.00
Compare Ask a question Share

Tolerance Analysis of Electronic Circuits Using MATHCAD

A$121.60
A$121.60 A$152.00
Product description

Written for the practicing electronics professional, Tolerance Analysis of Electronic Circuits Using MATHCADä offers a comprehensive, step-by-step treatment of methods used to perform analyses essential to the design process of circuit cards and systems of cards, including:

  • worst-case analysis,
  • limits for production testing,
  • component stress analysis,
  • determining if a design meets specification limits, and
  • manufacturing yield analysis
    Using a practical approach that allows engineers and technicians to put the techniques directly into practice, the author presents the mathematical procedures used to determine performance limits. The topics and techniques discussed include extreme value and root-sum-square analysis using symmetric and asymmetric tolerance, Monte Carlo analysis using normal and uniform distributions, sensitivity formulas, tolerance analyses of opamp offsets, and anomalies of high-Q ac circuits.
